دیتاشیت VND1NV04-1-E

VNx1NV04

مشخصات دیتاشیت

نام دیتاشیت VNx1NV04
حجم فایل 410.941 کیلوبایت
نوع فایل pdf
تعداد صفحات 33

دانلود دیتاشیت VNx1NV04

VNx1NV04 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: OMNIFET II™, VIPower™
  • Packaging: Tube
  • Part Status: Obsolete
  • Switch Type: General Purpose
  • Number of Outputs: 1
  • Ratio - Input:Output: 1:1
  • Output Configuration: Low Side
  • Output Type: N-Channel
  • Interface: On/Off
  • Voltage - Load: 36V (Max)
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 1.7A
  • Rds On (Typ): 250mOhm (Max)
  • Input Type: Non-Inverting
  • Features: -
  • Fault Protection: Current Limiting (Fixed), Over Temperature, Over Voltage
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: DPAK
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Base Part Number: VND1N
  • detail: Power Switch/Driver 1:1 N-Channel 1.7A DPAK
