SN74LVC2G08MDCUREP دیتاشیت

SN74LVC2G08MDCUREP

مشخصات دیتاشیت

نام دیتاشیت SN74LVC2G08MDCUREP
حجم فایل 91.136 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

مشاهده دیتاشیت SN74LVC2G08MDCUREP

دانلود دیتاشیت

سایر مستندات

SN74LVC2G08-EP 12 pages

مشخصات فنی

  • RoHS: true
  • Series: 74LVC
  • Category: Logic ICs/Gates
  • Datasheet: Texas Instruments SN74LVC2G08MDCUREP
  • Sink Current: 24mA
  • Source Current: 24mA
  • Supply Voltage: 1.65V~5.5V
  • Logic Gate Type: And
  • Number of Channels: 2
  • Low Level Range (VIL): 0.7V~0.8V
  • Operating Temperature: -55°C~+125°C
  • High Level Range (VIH): 1.7V~2V
  • Propagation Delay Time: 4.8ns@5V,50pF
  • Quiescent Current (Max): 10uA
  • Package: VSON-8(2.3x2.3)
  • Manufacturer: Texas Instruments
  • Logic Level - High: 1.7V ~ 2V
  • Base Part Number: SN74LVC2G
  • Supplier Device Package: 8-VSSOP
  • Logic Level - Low: 0.7V ~ 0.8V
  • Package / Case: 8-VFSOP (0.091", 2.30mm Width)
  • Current - Quiescent (Max): 10µA
  • Current - Output High, Low: 24mA, 24mA
  • Features: -
  • Mounting Type: Surface Mount
  • Packaging: Cut Tape (CT)
  • Voltage - Supply: 1.65V ~ 5.5V
  • Number of Circuits: 2
  • Max Propagation Delay @ V, Max CL: 4.8ns @ 5V, 50pF
  • Number of Inputs: 2
  • Part Status: Active
  • Logic Type: AND Gate
  • detail: AND Gate IC 2 Channel 8-VSSOP
