TMUX1102DBVR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TMUX1102DBVR	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TMUX1102DBVR
Supply Voltage: 1.08V~5.5V
Switch Circuit: SPST(SPST)
Number of Channels: 1
On-State Resistance (Max): 4Ω
Package: SOT-23-5
Manufacturer: Texas Instruments
Voltage - Supply, Single (V+): 1.08V ~ 5.5V
Multiplexer/Demultiplexer Circuit: 1:1
Current - Leakage (IS(off)) (Max): 80pA
Crosstalk: -
Voltage - Supply, Dual (V±): 1.08V ~ 5.5V
Packaging: Cut Tape (CT)
Channel-to-Channel Matching (ΔRon): 850mOhm
Charge Injection: -1.5pC
Supplier Device Package: SOT-23-5
-3db Bandwidth: 300MHz
Base Part Number: TMUX11
Mounting Type: Surface Mount
Channel Capacitance (CS(off), CD(off)): 6pF, 10pF
Switch Time (Ton, Toff) (Max): -
Operating Temperature: -40°C ~ 125°C (TA)
Number of Circuits: 1
Series: -
Package / Case: SC-74A, SOT-753
Part Status: Active
detail: 1 Circuit IC Switch 1:1 4Ohm SOT-23-5
