STL105DN4LF7AG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت STL105DN4LF7AG	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: STMicroelectronics
Series: Automotive, AEC-Q101, STripFET™ F7
Packaging: Tape & Reel (TR)
Part Status: Active
FET Type: 2 N-Channel (Dual)
FET Feature: Standard
Drain to Source Voltage (Vdss): 40V
Current - Continuous Drain (Id) @ 25°C: 40A (Tc)
Rds On (Max) @ Id, Vgs: 4.5mOhm @ 12A, 10V
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 27.5nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 1594pF @ 25V
Power - Max: 94W
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Surface Mount
Package / Case: 8-PowerVDFN
Supplier Device Package: PowerFlat™ (5x6)
detail: Mosfet Array 2 N-Channel (Dual) 40V 40A (Tc) 94W Surface Mount PowerFlat™ (5x6)
