STL13DP10F6 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت STL13DP10F6	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: STMicroelectronics
Series: DeepGATE™, STripFET™ VI
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
FET Type: 2 P-Channel (Dual)
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 100V
Current - Continuous Drain (Id) @ 25°C: 13A
Rds On (Max) @ Id, Vgs: 180mOhm @ 1.7A, 10V
Vgs(th) (Max) @ Id: 4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 16.5nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 864pF @ 25V
Power - Max: 62.5W
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 8-PowerVDFN
Supplier Device Package: PowerFlat™ (5x6)
Base Part Number: STL13
detail: Mosfet Array 2 P-Channel (Dual) 100V 13A 62.5W Surface Mount PowerFlat™ (5x6)
