ISO7021FDR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ISO7021FDR	دانلود دیتاشیت

ISO7021 34 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Digital Isolators
Data Rate: 4Mbps
Datasheet: Texas Instruments ISO7021FDR
Applications: General-purpose
Supply Voltage: 1.71V~1.89V;2.25V~5.5V
Forward Channel: 1
Reverse channel: 1
Number of Channels: 2
Isolation Technology: 电容隔离
Operating Temperature: -55°C~+125°C
Voltage Isolation or Not: Without voltage isolation
Package: SOP-8
Manufacturer: Texas Instruments
Channel Type: Unidirectional
Pulse Width Distortion (Max): 10ns
Type: General Purpose
Isolated Power: No
Series: -
Packaging: Cut Tape (CT)
Voltage - Supply: 1.71V ~ 1.89V, 2.25V ~ 5.5V
Propagation Delay tpLH / tpHL (Max): 165ns, 165ns
Common Mode Transient Immunity (Min): 100kV/µs
Technology: Capacitive Coupling
Supplier Device Package: 8-SOIC
Base Part Number: ISO702
Inputs - Side 1/Side 2: 1/1
Voltage - Isolation: 3000Vrms
Mounting Type: Surface Mount
Part Status: Active
Rise / Fall Time (Typ): 5ns, 5ns
Package / Case: 8-SOIC (0.154", 3.90mm Width)
detail: General Purpose Digital Isolator 3000Vrms 2 Channel 4Mbps 100kV/µs CMTI 8-SOIC (0.154", 3.90mm Width)
