مشاهده دیتاشیت MP23AB01DM	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: STMicroelectronics
Series: -
Packaging: Tray
Part Status: Active
Type: MEMS (Silicon)
Output Type: Analog
Direction: Omnidirectional
Frequency Range: 100Hz ~ 10kHz
Sensitivity: -38dB ±3dB @ 94dB SPL
S/N Ratio: 64dB
Impedance: 400 Ohms
Voltage Range: 2.1V ~ 3.6V
Current - Supply: 250µA
Port Location: Bottom
Ratings: -
Termination: Surface Mount
Size / Dimension: 0.132" L x 0.098" W (3.35mm x 2.50mm)
Height (Max): 0.043" (1.08mm)
Shape: Rectangular
Base Part Number: MP23
detail: 100Hz ~ 10kHz Analog Microphone MEMS (Silicon) 2.1V ~ 3.6V Omnidirectional (-38dB ±3dB @ 94dB SPL) Surface Mount
