DRV8884 Datasheet دیتاشیت

DRV8884 Datasheet

مشخصات دیتاشیت

نام دیتاشیت DRV8884 Datasheet
حجم فایل 3199.472 کیلوبایت
نوع فایل pdf
تعداد صفحات 50

مشاهده دیتاشیت DRV8884 Datasheet

دانلود دیتاشیت

سایر مستندات

DRV8884PWPR 46 pages

مشخصات فنی

  • RoHS: true
  • Type: -
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: Texas Instruments DRV8884PWPR
  • Interface: -
  • Output Current: 1A
  • Supply Voltage: 0V~5.3V
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: TSSOP-24-EP
  • Manufacturer: Texas Instruments
  • Series: -
  • Technology: Power MOSFET
  • Package / Case: 24-TSSOP (0.173", 4.40mm Width) Exposed Pad
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Current - Output: 1A
  • Part Status: Active
  • Base Part Number: DRV8884
  • Mounting Type: Surface Mount
  • Motor Type - Stepper: Bipolar
  • Applications: General Purpose
  • Motor Type - AC, DC: -
  • Voltage - Supply: 0V ~ 5.3V
  • Step Resolution: 1 ~ 1/16
  • Packaging: Tube
  • Output Configuration: Half Bridge (4)
  • Voltage - Load: 8V ~ 37V
  • Supplier Device Package: 24-HTSSOP
  • detail: Bipolar Motor Driver Power MOSFET Logic 24-HTSSOP
