دیتاشیت TPS2HB35AQPWPRQ1
مشخصات دیتاشیت
| نام دیتاشیت |
TPS2HB35-Q1
|
| حجم فایل |
2035.875
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
58
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Power Distribution Switches
-
Datasheet:
Texas Instruments TPS2HB35AQPWPRQ1
-
Package:
TSSOP-16
-
Manufacturer:
Texas Instruments
-
Rds On (Typ):
35mOhm
-
Voltage - Supply (Vcc/Vdd):
Not Required
-
Switch Type:
General Purpose
-
Supplier Device Package:
16-HTSSOP
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Output Configuration:
High Side
-
Output Type:
N-Channel
-
Features:
-
-
Fault Protection:
Current Limiting (Adjustable), Over Temperature
-
Voltage - Load:
3V ~ 28V
-
Mounting Type:
Surface Mount
-
Interface:
On/Off
-
Ratio - Input:Output:
1:1
-
Series:
Automotive, AEC-Q100
-
Input Type:
-
-
Package / Case:
16-PowerTSSOP (0.173", 4.40mm Width)
-
Number of Outputs:
2
-
Part Status:
Active
-
Current - Output (Max):
36A
-
detail:
Power Switch/Driver 1:1 N-Channel 36A 16-HTSSOP
