دانلود دیتاشیت ISO7721 Datasheet	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Channel Type: Unidirectional
Pulse Width Distortion (Max): 4.9ns
Type: CAN, RS232, RS485
Number of Channels: 2
Isolated Power: No
Series: -
Packaging: Cut Tape (CT)
Voltage - Supply: 2.25V ~ 5.5V
Propagation Delay tpLH / tpHL (Max): 16ns, 16ns
Common Mode Transient Immunity (Min): 85kV/µs
Data Rate: 100Mbps
Technology: Capacitive Coupling
Supplier Device Package: 16-SOIC
Base Part Number: ISO772
Inputs - Side 1/Side 2: 1/1
Voltage - Isolation: 5000Vrms
Operating Temperature: -55°C ~ 125°C
Mounting Type: Surface Mount
Manufacturer: Texas Instruments
Part Status: Active
Rise / Fall Time (Typ): 1.8ns, 1.9ns
Package / Case: 16-SOIC (0.295", 7.50mm Width)
detail: CAN, RS232, RS485 Digital Isolator 5000Vrms 2 Channel 100Mbps 85kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
