دیتاشیت TPS54617RUVR/2801

TPS54617

مشخصات دیتاشیت

نام دیتاشیت TPS54617
حجم فایل 903.994 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت TPS54617

TPS54617 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Function: Step-down type
  • Topology: Step-down
  • Datasheet: Texas Instruments TPS54617RUVR/2801
  • Output Type: Adjustable
  • Input Voltage: 3V~6V
  • Output Voltage: 0.891V~5.4V
  • Number of Outputs: 1
  • Switching Frequency: 350kHz;550kHz
  • Output Current (Max): 6A
  • Operating Temperature: -40°C~+125°C@(TJ)
  • Synchronous Rectification: Yes
  • Package: QFN-34-EP(3.5x7)
  • Manufacturer: Texas Instruments
  • Supplier Device Package: 34-VQFN (7x3.5)
  • Voltage - Input (Min): 3V
  • Voltage - Output (Max): 5.4V
  • Output Configuration: Positive
  • Mounting Type: Surface Mount
  • Current - Output: 6A
  • Synchronous Rectifier: Yes
  • Frequency - Switching: 350kHz, 550kHz
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Min/Fixed): 0.891V
  • Series: SWIFT™
  • Base Part Number: TPS546
  • Voltage - Input (Max): 6V
  • Part Status: Active
  • Package / Case: 34-VFQFN Exposed Pad
  • detail: Buck Switching Regulator IC Positive Adjustable 0.891V 1 Output 6A 34-VFQFN Exposed Pad
