دیتاشیت LM5032MTCX/NOPB
مشخصات دیتاشیت
| نام دیتاشیت |
LM5032
|
| حجم فایل |
1680.817
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
36
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Controllers
-
Function:
Buck-boost type
-
Topology:
Forward
-
Datasheet:
Texas Instruments LM5032MTCX/NOPB
-
Input Voltage:
13V~100V
-
Duty Cycle (Max):
76%
-
Number of Outputs:
2
-
Switching Frequency:
200kHz;600kHz
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
TSSOP-16
-
Manufacturer:
Texas Instruments
-
Voltage - Supply (Vcc/Vdd):
13V ~ 100V
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
-
Base Part Number:
LM5032
-
Clock Sync:
Yes
-
Control Features:
Frequency Control, Soft Start
-
Part Status:
Obsolete
-
Series:
-
-
Mounting Type:
Surface Mount
-
Output Type:
Transistor Driver
-
Output Configuration:
Positive
-
Synchronous Rectifier:
No
-
Frequency - Switching:
200kHz, 600kHz
-
Supplier Device Package:
16-TSSOP
-
Packaging:
Tape & Reel (TR)
-
Output Phases:
2
-
Serial Interfaces:
-
-
detail:
Forward Converter Regulator Positive Output Step-Up/Step-Down DC-DC Controller IC 16-TSSOP
