دیتاشیت DRV8832DGQR

DRV8832

مشخصات دیتاشیت

نام دیتاشیت DRV8832
حجم فایل 2227.916 کیلوبایت
نوع فایل pdf
تعداد صفحات 29

دانلود دیتاشیت DRV8832

DRV8832 Datasheet

مشخصات

  • RoHS: true
  • Type: Brush DC Motor
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: Texas Instruments DRV8832DGQR
  • Interface: Parallel
  • Output Current: 1A
  • Supply Voltage: 2.75V~6.8V
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: MSOP-10-EP
  • Manufacturer: Texas Instruments
  • Motor Type - Stepper: Bipolar
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Supplier Device Package: 10-MSOP-PowerPad
  • Applications: Battery Powered
  • Step Resolution: -
  • Voltage - Load: 2.75V ~ 6.8V
  • Mounting Type: Surface Mount
  • Voltage - Supply: 2.75V ~ 6.8V
  • Packaging: Cut Tape (CT)
  • Motor Type - AC, DC: Brushed DC
  • Output Configuration: Half Bridge (2)
  • Series: -
  • Base Part Number: DRV8832
  • Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
  • Current - Output: 1A
  • Part Status: Active
  • Technology: Power MOSFET
  • detail: Bipolar Motor Driver Power MOSFET Parallel 10-MSOP-PowerPad
