TLC5946PWPR Datasheet
Datasheet specifications
| Datasheet's name | TLC5946PWPR |
|---|---|
| File size | 61.324 KB |
| File type | |
| Number of pages | 44 |
Download Datasheet TLC5946PWPR |
Download Datasheet |
|---|
Other documentations
TLC5946 Datasheet 43 pages
Technical specifications
- RoHS: true
- Category: Nixie Tube Driver/LED Driver/LED Drivers
- Datasheet: Texas Instruments TLC5946PWPR
- Package: HTSSOP-28-EP
- Manufacturer: Texas Instruments
- Series: -
- Type: Linear
- Package / Case: 28-TSSOP (0.173", 4.40mm Width)
- Frequency: 30MHz
- Number of Outputs: 16
- Topology: Shift Register
- Part Status: Active
- Mounting Type: Surface Mount
- Operating Temperature: -40°C ~ 85°C (TA)
- Internal Switch(s): Yes
- Applications: Backlight, Signage
- Voltage - Supply (Min): 3V
- Current - Output / Channel: 40mA
- Voltage - Output: 17V
- Packaging: Tube
- Base Part Number: TLC594
- Supplier Device Package: 28-TSSOP
- Voltage - Supply (Max): 5.5V
- Dimming: -
- detail: LED Driver IC 16 Output Linear Shift Register Dimming 40mA 28-TSSOP
