TXN825RG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TXN825RG
|
|
حجم فایل
|
231.247
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
Manufacturer:
STMicroelectronics
-
Series:
ECOPACK®2
-
Packaging:
Tube
-
Part Status:
Active
-
Voltage - Off State:
800mV
-
Voltage - Gate Trigger (Vgt) (Max):
1.3V
-
Current - Gate Trigger (Igt) (Max):
40mA
-
Voltage - On State (Vtm) (Max):
1.6V
-
Current - On State (It (AV)) (Max):
16A
-
Current - On State (It (RMS)) (Max):
25A
-
Current - Hold (Ih) (Max):
50mA
-
Current - Off State (Max):
5µA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
300A, 314A
-
SCR Type:
Standard Recovery
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3
-
Supplier Device Package:
TO-220AB Insulated
-
detail:
SCR 800mV 25A Standard Recovery Through Hole TO-220AB Insulated
