TMUX1109RSVR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TMUX1109RSVR
|
|
حجم فایل
|
93.252
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
40
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TMUX1109RSVR
-
Switch Circuit:
-
-
Package:
UQFN-16(1.8x2.6)
-
Manufacturer:
Texas Instruments
-
Crosstalk:
-90dB ~ -80dB @ 1MHz ~ 10MHz
-
Multiplexer/Demultiplexer Circuit:
4:1
-
Supplier Device Package:
16-UQFN (2.6x1.8)
-
On-State Resistance (Max):
4Ohm
-
-3db Bandwidth:
135MHz
-
Switch Time (Ton, Toff) (Max):
12ns, 6ns (Typ)
-
Series:
-
-
Current - Leakage (IS(off)) (Max):
80pA
-
Mounting Type:
Surface Mount
-
Charge Injection:
-1pC
-
Channel Capacitance (CS(off), CD(off)):
7.5pF, 32pF
-
Packaging:
Cut Tape (CT)
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Number of Circuits:
2
-
Voltage - Supply, Dual (V±):
±2.75V
-
Channel-to-Channel Matching (ΔRon):
180mOhm
-
Base Part Number:
TMUX11
-
Part Status:
Active
-
Package / Case:
16-UFQFN
-
detail:
2 Circuit IC Switch 4:1 4Ohm 16-UQFN (2.6x1.8)
