TMUX6122DGSR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TMUX6122DGSR
|
|
حجم فایل
|
88.714
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
32
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TMUX6122DGSR
-
Turn-on time:
86ns
-
Turn-off time:
76ns
-
Switch Circuit:
SPST(SPST)
-
Number of Channels:
2
-
On-State Resistance (Max):
165Ω
-
Package:
MSOP-10
-
Manufacturer:
Texas Instruments
-
Crosstalk:
-110dB @ 1MHz
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Supplier Device Package:
10-VSSOP
-
-3db Bandwidth:
630MHz
-
Switch Time (Ton, Toff) (Max):
86ns, 76ns
-
Series:
-
-
Current - Leakage (IS(off)) (Max):
20pA
-
Mounting Type:
Surface Mount
-
Charge Injection:
0.51pC
-
Channel Capacitance (CS(off), CD(off)):
1.9pF, 2.2pF
-
Packaging:
Cut Tape (CT)
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Number of Circuits:
2
-
Voltage - Supply, Dual (V±):
±5V ~ 16.5V
-
Channel-to-Channel Matching (ΔRon):
2.4Ohm
-
Base Part Number:
TMUX61
-
Part Status:
Active
-
Package / Case:
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
-
detail:
2 Circuit IC Switch 1:1 165Ohm 10-VSSOP
