دیتاشیت TS5MP646NYFPR

مشخصات دیتاشیت

دانلود دیتاشیت TS5MP646 Datasheet	TS5MP646 Datasheet Datasheet

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TS5MP646NYFPR
Supply Voltage: 1.65V~5.5V
Switch Circuit: SPDT(SPDT)
Number of Channels: 10
On-State Resistance (Max): 9Ω
Package: BGA-36
Manufacturer: Texas Instruments
Voltage - Supply, Single (V+): 1.65V ~ 5.5V
Multiplexer/Demultiplexer Circuit: 2:1
Current - Leakage (IS(off)) (Max): 500nA
Crosstalk: -40dB @ 1.25GHz
Voltage - Supply, Dual (V±): -
Packaging: Cut Tape (CT)
Channel-to-Channel Matching (ΔRon): 100mOhm
Charge Injection: -
Supplier Device Package: 36-DSBGA
-3db Bandwidth: 3GHz
Base Part Number: TS5MP6
Mounting Type: Surface Mount
Channel Capacitance (CS(off), CD(off)): 1.5pF
Switch Time (Ton, Toff) (Max): -
Operating Temperature: -40°C ~ 85°C
Number of Circuits: 10
Series: -
Package / Case: 36-XFBGA, DSBGA
Part Status: Active
detail: 10 Circuit IC Switch 2:1 9Ohm 36-DSBGA
