AST1S31HF دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
AST1S31HF
|
|
حجم فایل
|
74.493
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
33
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
STMicroelectronics AST1S31HF
-
Output Type:
Adjustable
-
Input Voltage:
2.8V~4V
-
Output Voltage:
0.8V~4V
-
Number of Outputs:
1
-
Switching Frequency:
2.3MHz
-
Output Current (Max):
3A
-
Operating Temperature:
-40°C~+150°C@(TJ)
-
Synchronous Rectification:
Yes
-
Package:
VFDFPN-8(3x3)
-
Manufacturer:
STMicroelectronics
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
Output Configuration:
Positive
-
Voltage - Input (Min):
2.8V
-
Voltage - Input (Max):
4V
-
Voltage - Output (Min/Fixed):
0.8V
-
Voltage - Output (Max):
4V
-
Current - Output:
3A
-
Frequency - Switching:
2.3MHz
-
Synchronous Rectifier:
Yes
-
Mounting Type:
Surface Mount
-
Package / Case:
8-VDFN Exposed Pad
-
Supplier Device Package:
8-VFDFPN (3x3)
-
Base Part Number:
AST1S31
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 3A 8-VDFN Exposed Pad
