TPS76733QDR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS76733QDR
|
|
حجم فایل
|
91.763
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
32
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS76733QDR
-
Output Current:
1A
-
Output Voltage:
3.3V
-
Dropout Voltage:
0.58V@(1A)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
10V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
125uA
-
Power Supply Rejection Ratio (PSRR):
60dB@(1kHz)
-
Package:
SOP-8
-
Manufacturer:
Texas Instruments
-
Base Part Number:
TPS767
-
Supplier Device Package:
8-SOIC
-
Voltage - Output (Max):
-
-
Output Configuration:
Positive
-
Current - Quiescent (Iq):
125µA
-
Output Type:
Fixed
-
PSRR:
60dB (1kHz)
-
Voltage Dropout (Max):
0.58V @ 1A
-
Number of Regulators:
1
-
Mounting Type:
Surface Mount
-
Packaging:
Cut Tape (CT)
-
Voltage - Output (Min/Fixed):
3.3V
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity
-
Series:
-
-
Voltage - Input (Max):
10V
-
Current - Output:
1A
-
Part Status:
Active
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Control Features:
Enable, Reset
-
detail:
Linear Voltage Regulator IC 1 Output 1A 8-SOIC
