Signal e-Book: OP Amp Design Topics دیتاشیت

Signal e-Book: OP Amp Design Topics

مشخصات دیتاشیت

نام دیتاشیت Signal e-Book: OP Amp Design Topics
حجم فایل 17975.467 کیلوبایت
نوع فایل pdf
تعداد صفحات 37

دانلود دیتاشیت Signal e-Book: OP Amp Design Topics

دانلود دیتاشیت

سایر مستندات

OPA27GU 24 pages

OPA27, OPA37 Datasheet 23 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments OPA37GU/2K5
  • -3db Bandwidth: -
  • Output Current: 25mA
  • Number of Circuits: 1
  • Operating Temperature: -40°C~+85°C
  • Current - Input Bias(Ib): 15nA
  • Gain Bandwidth Product(GBP): 63MHz
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Current - Output / Channel: 25mA
  • Current - Supply: 3.3mA
  • Voltage - Input Offset: 25µV
  • Supplier Device Package: 8-SOIC
  • Slew Rate: 11.9V/µs
  • Amplifier Type: General Purpose
  • Mounting Type: Surface Mount
  • Output Type: -
  • Current - Input Bias: 15nA
  • Gain Bandwidth Product: 63MHz
  • Base Part Number: OPA37
  • Packaging: Cut Tape (CT)
  • Series: -
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Part Status: Active
  • Voltage - Supply, Single/Dual (±): 8V ~ 44V, ±4V ~ 22V
  • detail: General Purpose Amplifier 1 Circuit 8-SOIC
