L5989D ~ دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت L5989D ~	دانلود دیتاشیت

L5989D 51 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Datasheet: STMicroelectronics L5989DTR
Package: TSSOP-16-EP
Manufacturer: STMicroelectronics
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Function: Step-Down
Output Configuration: Positive
Topology: Buck
Output Type: Adjustable
Number of Outputs: 1
Voltage - Input (Min): 2.9V
Voltage - Input (Max): 18V
Voltage - Output (Min/Fixed): 0.6V
Voltage - Output (Max): 18V
Current - Output: 4A
Frequency - Switching: 100kHz ~ 1MHz
Synchronous Rectifier: Yes
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package: 16-HTSSOP
Base Part Number: L5989
detail: Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 4A 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
