دیتاشیت MUX506IPWR
مشخصات دیتاشیت
| نام دیتاشیت | MUX506, MUX507 Datasheet |
|---|---|
| حجم فایل | 1481.518 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 43 |
دانلود دیتاشیت MUX506, MUX507 Datasheet |
MUX506, MUX507 Datasheet Datasheet |
|---|
مشخصات
- Voltage - Supply, Single (V+): 10V ~ 36V
- Multiplexer/Demultiplexer Circuit: 16:1
- Current - Leakage (IS(off)) (Max): 1nA
- Crosstalk: -100dB @ 1MHz
- Voltage - Supply, Dual (V±): ±5V ~ 18V
- Packaging: Cut Tape (CT)
- Channel-to-Channel Matching (ΔRon): 6Ohm
- Charge Injection: 0.31pC
- Switch Circuit: -
- Supplier Device Package: 28-TSSOP
- On-State Resistance (Max): 200Ohm
- -3db Bandwidth: -
- Base Part Number: MUX506
- Mounting Type: Surface Mount
- Channel Capacitance (CS(off), CD(off)): 3pF, 12.2pF
- Switch Time (Ton, Toff) (Max): 136ns, 78ns
- Operating Temperature: -40°C ~ 125°C (TA)
- Number of Circuits: 1
- Series: -
- Package / Case: 28-TSSOP (0.173", 4.40mm Width)
- Part Status: Active
- Manufacturer: Texas Instruments
- detail: 1 Circuit IC Switch 16:1 200Ohm 28-TSSOP
