دیتاشیت L5963DN-EHT

L5963 Datasheet

مشخصات دیتاشیت

نام دیتاشیت L5963 Datasheet
حجم فایل 963.371 کیلوبایت
نوع فایل pdf
تعداد صفحات 49

دانلود دیتاشیت L5963 Datasheet

L5963 Datasheet Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Topology: Step-Down (Buck) Synchronous (2), Linear (LDO) (1)
  • Number of Outputs: 3
  • Frequency - Switching: 250kHz ~ 2MHz
  • Voltage/Current - Output 1: Programmable, 2.5A
  • Voltage/Current - Output 2: Programmable, 3A
  • Voltage/Current - Output 3: Programmable, 250mA
  • w/LED Driver: No
  • w/Supervisor: Yes
  • w/Sequencer: Yes
  • Voltage - Supply: 3.5V ~ 26V
  • Operating Temperature: -40°C ~ 105°C
  • Mounting Type: Surface Mount
  • Package / Case: 36-PowerFSOP (0.295", 7.50mm Width)
  • Supplier Device Package: PowerSSO-36
  • Base Part Number: L5963
  • detail: PMIC - Voltage Regulators - Linear + Switching 3 Output Step-Down (Buck) Synchronous (2), Linear (LDO) (1) 250kHz ~ 2MHz PowerSSO-36
