CSD97370Q5M دیتاشیت

CSD97370Q5M

مشخصات دیتاشیت

نام دیتاشیت CSD97370Q5M
حجم فایل 75.86 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

مشاهده دیتاشیت CSD97370Q5M

دانلود دیتاشیت

سایر مستندات

CSD97370Q5M 20 pages

مشخصات فنی

  • RoHS: true
  • Feature: -
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Texas Instruments CSD97370Q5M
  • Supply Voltage: 4.5V~5.5V
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: LSON-22-EP(5x6)
  • Manufacturer: Texas Instruments
  • Current - Output / Channel: 40A
  • Current - Peak Output: 60A
  • Supplier Device Package: 22-LSON-CLIP (6x5)
  • Applications: Synchronous Buck Converters
  • Output Configuration: Half Bridge
  • Load Type: Inductive
  • Features: Bootstrap Circuit
  • Fault Protection: Shoot-Through, UVLO
  • Voltage - Load: 3.3V ~ 22V
  • Mounting Type: Surface Mount
  • Voltage - Supply: 4.5V ~ 5.5V
  • Interface: PWM
  • Packaging: Cut Tape (CT)
  • Rds On (Typ): -
  • Series: NexFET™
  • Package / Case: 22-PowerLFDFN
  • Base Part Number: CSD97370
  • Part Status: Active
  • Technology: Power MOSFET
  • detail: Half Bridge Driver Synchronous Buck Converters Power MOSFET 22-LSON-CLIP (6x5)
