TMUX1133PWR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TMUX1133PWR	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TMUX1133PWR
Turn-on time: 12ns
Turn-off time: 6ns
Supply Voltage: 1.08V~5.5V
Switch Circuit: SPDT(SPDT)
Number of Channels: 3
On-State Resistance (Max): 4Ω
Package: TSSOP-16
Manufacturer: Texas Instruments
Crosstalk: -90dB @ 10MHz
Multiplexer/Demultiplexer Circuit: 2:1
Supplier Device Package: 16-TSSOP
-3db Bandwidth: 220MHz
Switch Time (Ton, Toff) (Max): 12ns, 6ns (Typ)
Series: -
Current - Leakage (IS(off)) (Max): 80pA
Package / Case: 16-TSSOP (0.173", 4.40mm Width)
Charge Injection: -1pC
Channel Capacitance (CS(off), CD(off)): 6pF, 17pF
Packaging: Cut Tape (CT)
Operating Temperature: -40°C ~ 125°C (TA)
Number of Circuits: 3
Voltage - Supply, Dual (V±): -
Base Part Number: TMUX11
Channel-to-Channel Matching (ΔRon): 180mOhm
Part Status: Active
Voltage - Supply, Single (V+): 1.08V ~ 5.5V
detail: 3 Circuit IC Switch 2:1 4Ohm 16-TSSOP
