LM9070SX/NOPB دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LM9070SX/NOPB	دانلود دیتاشیت

LM9070 18 pages

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments LM9070SX/NOPB
Output Current: 250mA
Output Voltage: 5V
Dropout Voltage: 0.8V@(250mA)
Output Polarity: positive
Number of Outputs: 1
Maximum Input Voltage: 26V
Operating Temperature: -40°C~+125°C
Quiescent Current (Ground Current): 4mA
Power Supply Rejection Ratio (PSRR): 60dB@(120Hz)
Package: TO-263-7
Manufacturer: Texas Instruments
Control Features: Enable
Base Part Number: LM9070
Package / Case: TO-263-8, D²Pak (7 Leads + Tab), TO-263CA
Current - Supply (Max): 50mA
Part Status: Obsolete
Current - Output: 250mA
PSRR: 60dB (120Hz)
Series: -
Voltage - Output (Min/Fixed): 5V
Mounting Type: Surface Mount
Number of Regulators: 1
Current - Quiescent (Iq): 4mA
Output Configuration: Positive
Voltage Dropout (Max): 0.8V @ 250mA
Supplier Device Package: DDPAK/TO-263-7
Protection Features: Over Temperature, Over Voltage, Reverse Polarity, Short Circuit
Voltage - Input (Max): 26V
Output Type: Fixed
Packaging: Tape & Reel (TR)
Voltage - Output (Max): -
detail: Linear Voltage Regulator IC 1 Output 250mA DDPAK/TO-263-7
