دیتاشیت UC2572DTR
مشخصات دیتاشیت
| نام دیتاشیت | UC2572DTR |
|---|---|
| حجم فایل | 78.85 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 9 |
UC2572DTR |
دانلود دیتاشیت |
|---|
سایر مستندات
UC1572, 2572, 3572 9 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Function: Buck-boost type
- Topology: Flyback
- Datasheet: Texas Instruments UC2572DTR
- Input Voltage: 4.75V~30V
- Duty Cycle (Max): 92%
- Number of Outputs: 1
- Switching Frequency: 100kHz
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: NO
- Package: SOIC-8
- Manufacturer: Texas Instruments
- Output Phases: 1
- Series: -
- Output Configuration: Negative
- Output Type: Transistor Driver
- Clock Sync: No
- Packaging: Cut Tape (CT)
- Synchronous Rectifier: No
- Voltage - Supply (Vcc/Vdd): 4.75V ~ 30V
- Supplier Device Package: 8-SOIC
- Serial Interfaces: -
- Frequency - Switching: 100kHz
- Mounting Type: Surface Mount
- Base Part Number: UC257
- Part Status: Active
- Control Features: Current Limit, Ramp
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- detail: Flyback Regulator Negative Output Step-Up/Step-Down DC-DC Controller IC 8-SOIC
