دیتاشیت DRV8805PWPR

DRV8805 Datasheet

مشخصات دیتاشیت

نام دیتاشیت DRV8805 Datasheet
حجم فایل 1744.004 کیلوبایت
نوع فایل pdf
تعداد صفحات 29

دانلود دیتاشیت DRV8805 Datasheet

DRV8805 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: Texas Instruments DRV8805PWPR
  • Package: TSSOP-16-EP
  • Manufacturer: Texas Instruments
  • Motor Type - Stepper: Unipolar
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Supplier Device Package: 16-HTSSOP
  • Applications: General Purpose
  • Step Resolution: 1, 1/2
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Voltage - Load: 8.2V ~ 60V
  • Mounting Type: Surface Mount
  • Voltage - Supply: 8.2V ~ 60V
  • Interface: Logic
  • Packaging: Cut Tape (CT)
  • Motor Type - AC, DC: Brushed DC
  • Output Configuration: Low Side (4)
  • Series: -
  • Base Part Number: DRV8805
  • Package / Case: 16-PowerTSSOP (0.173", 4.40mm Width)
  • Current - Output: 1A
  • Part Status: Active
  • Technology: Power MOSFET
  • detail: Unipolar Motor Driver Power MOSFET Logic 16-HTSSOP
