دیتاشیت STA8090WGR
مشخصات دیتاشیت
| نام دیتاشیت |
STA8090WGR
|
| حجم فایل |
708.975
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
32
|
مشخصات
-
RoHS:
true
-
Category:
IoT/Communication Modules/Satellite Positioning Modules
-
Datasheet:
STMicroelectronics STA8090WGR
-
GNSS Type:
BeiDou;Galileo;GLONASS;GNSS;GPS
-
Sensitivity:
-162dBm
-
Interface Type:
I2C;SPI;UART;USB
-
Operating Temperature:
-40°C~+85°C
-
Operating Supply Voltage:
1.08V~1.32V
-
Package:
WLCSP-77
-
Manufacturer:
STMicroelectronics
-
Series:
Automotive, AEC-Q100
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Frequency:
4.092MHz ~ 1.561GHz, 8.57MHz ~ 1.575GHz, 10.23MHz ~ 1.601GHz
-
Data Rate (Max):
12Mbps
-
Modulation or Protocol:
BeiDou, Galileo, GLONASS, GNSS, GPS
-
Applications:
GPS Receiver
-
Current - Receiving:
-
-
Data Interface:
I²C, SPI, UART, USB
-
Memory Size:
256kB SRAM, 512kB ROM
-
Antenna Connector:
PCB, Surface Mount
-
Features:
-
-
Voltage - Supply:
1.08V ~ 1.32V
-
Mounting Type:
Surface Mount
-
Package / Case:
77-UFBGA, WLCSP
-
Supplier Device Package:
77-WLCSP (3.86x3.84)
-
detail:
Automotive, AEC-Q100 RF Receiver BeiDou, Galileo, GLONASS, GNSS, GPS 4.092MHz ~ 1.561GHz, 8.57MHz ~ 1.575GHz, 10.23MHz ~ 1.601GHz -162dBm 12Mbps PCB, Surface Mount 77-WLCSP (3.86x3.84)
