ISO5452 Datasheet دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ISO5452 Datasheet	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Gate Drive ICs
Datasheet: Texas Instruments ISO5452DWR
Fall Time: 20ns
Rise Time: 18ns
Number of Drivers: 1
Operating Temperature: -40°C~+125°C
Peak Output Current(sink): 3.4A
Peak Output Current(source): 1.5A
Package: SOP-16-300mil
Manufacturer: Texas Instruments
Pulse Width Distortion (Max): -
Current - Peak Output: 2.7A, 5.5A
Supplier Device Package: 16-SOIC
Number of Channels: 1
Mounting Type: Surface Mount
Voltage - Forward (Vf) (Typ): -
Voltage - Output Supply: 15V ~ 30V
Current - Output High, Low: 1.5A, 3.4A
Approval Agency: CQC, CSA, UR, VDE
Voltage - Isolation: 5700Vrms
Base Part Number: ISO545
Packaging: Cut Tape (CT)
Technology: Capacitive Coupling
Propagation Delay tpLH / tpHL (Max): 110ns, 110ns
Series: -
Package / Case: 16-SOIC (0.295", 7.50mm Width)
Common Mode Transient Immunity (Min): 50kV/µs
Part Status: Active
Rise / Fall Time (Typ): 18ns, 20ns
detail: 2.7A, 5.5A Gate Driver Capacitive Coupling 5700Vrms 1 Channel 16-SOIC
