LM5000SD-3/NOPB Datasheet

LM5000SD-3/NOPB

Datasheet specifications

Datasheet's name LM5000SD-3/NOPB
File size 85.782 KB
File type pdf
Number of pages 27

Download Datasheet LM5000SD-3/NOPB

Download Datasheet

Other documentations

LM5000 26 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Datasheet: Texas Instruments LM5000SD-3/NOPB
  • Package: DFN-16(5x5)
  • Manufacturer: Texas Instruments
  • Package / Case: 16-WFDFN Exposed Pad
  • Function: Step-Up, Step-Up/Step-Down
  • Output Configuration: Positive
  • Topology: Boost, Flyback, Forward Converter
  • Base Part Number: LM5000
  • Packaging: Cut Tape (CT)
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Frequency - Switching: 300kHz, 700kHz
  • Supplier Device Package: 16-WSON (5x5)
  • Part Status: Obsolete
  • Current - Output: 1.35A (Switch)
  • Number of Outputs: 1
  • Series: -
  • Voltage - Input (Max): 40V
  • Synchronous Rectifier: No
  • Voltage - Output (Min/Fixed): 3.1V
  • Voltage - Input (Min): 3.1V
  • Mounting Type: Surface Mount
  • Voltage - Output (Max): 80V (Switch)
  • Output Type: Adjustable
  • detail: Boost, Flyback, Forward Converter Switching Regulator IC Positive Adjustable 3.1V 1 Output 1.35A (Switch) 16-WFDFN Exposed Pad
