دیتاشیت VND5004A-E

VND5004A(SP30)-E

مشخصات دیتاشیت

نام دیتاشیت VND5004A(SP30)-E
حجم فایل 873.68 کیلوبایت
نوع فایل pdf
تعداد صفحات 34

دانلود دیتاشیت VND5004A(SP30)-E

VND5004A(SP30)-E Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: VIPower™
  • Packaging: Tray
  • Part Status: Active
  • Switch Type: General Purpose
  • Number of Outputs: 2
  • Ratio - Input:Output: 1:1
  • Output Configuration: High Side
  • Output Type: N-Channel
  • Interface: On/Off
  • Voltage - Load: 4.5V ~ 27V
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 70A
  • Rds On (Typ): 4mOhm (Max)
  • Input Type: Non-Inverting
  • Features: Auto Restart
  • Fault Protection: Current Limiting (Fixed), Over Temperature, Over Voltage
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 24-PQFN (12x12)
  • Package / Case: 24-PowerDFN
  • Base Part Number: VND5004
  • detail: Power Switch/Driver 1:1 N-Channel 70A 24-PQFN (12x12)
