UCC21521 Datasheet دیتاشیت

UCC21521 Datasheet

مشخصات دیتاشیت

نام دیتاشیت UCC21521 Datasheet
حجم فایل 1667.948 کیلوبایت
نوع فایل pdf
تعداد صفحات 47

دانلود دیتاشیت UCC21521 Datasheet

دانلود دیتاشیت

سایر مستندات

UCC21521ADW 51 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Texas Instruments UCC21521DWR
  • Package: SOP-16-300mil
  • Manufacturer: Texas Instruments
  • Pulse Width Distortion (Max): 5ns
  • Operating Temperature: -40°C ~ 125°C
  • Current - Peak Output: -
  • Supplier Device Package: 16-SOIC
  • Number of Channels: 2
  • Mounting Type: Surface Mount
  • Voltage - Forward (Vf) (Typ): -
  • Voltage - Output Supply: 9.2V ~ 25V
  • Current - Output High, Low: 4A, 6A
  • Voltage - Isolation: 5700Vrms
  • Base Part Number: UCC215
  • Packaging: Cut Tape (CT)
  • Technology: Capacitive Coupling
  • Propagation Delay tpLH / tpHL (Max): 30ns, 30ns
  • Series: -
  • Package / Case: 16-SOIC (0.295", 7.50mm Width)
  • Common Mode Transient Immunity (Min): 100V/ns
  • Part Status: Active
  • Rise / Fall Time (Typ): 6ns, 7ns
  • detail: Gate Driver Capacitive Coupling 5700Vrms 2 Channel 16-SOIC
