TLC2932IPWR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TLC2932IPWR
|
|
حجم فایل
|
83.624
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
24
|
مشخصات فنی
-
RoHS:
true
-
Category:
RTC/Clock Chip/Clock Generators / Frequency Synthesizers / PLL
-
Datasheet:
Texas Instruments TLC2932IPWR
-
Package:
TSSOP-14
-
Manufacturer:
Texas Instruments
-
Type:
Phase Lock Loop (PLL)
-
Supplier Device Package:
14-TSSOP
-
Package / Case:
14-TSSOP (0.173", 4.40mm Width)
-
Differential - Input:Output:
No/No
-
Voltage - Supply:
2.85V ~ 5.25V
-
Mounting Type:
Surface Mount
-
Operating Temperature:
-20°C ~ 75°C
-
Divider/Multiplier:
Yes/Yes
-
Output:
CMOS
-
Frequency - Max:
50MHz
-
Packaging:
Cut Tape (CT)
-
Ratio - Input:Output:
2:1
-
Number of Circuits:
1
-
Series:
-
-
PLL:
Yes
-
Base Part Number:
TLC293
-
Part Status:
Obsolete
-
Input:
CMOS
-
detail:
IC PHASE LOCK LOOP HP 14-TSSOP
