TMUX6104PWR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TMUX6104PWR	دانلود دیتاشیت

TMUX6104 31 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TMUX6104PWR
Turn-on time: 85ns
Turn-off time: 53ns
Supply Voltage: 10V~36V
Switch Circuit: 单刀四掷(SP4T)
Number of Channels: 1
On-State Resistance (Max): 200Ω
Package: TSSOP-14
Manufacturer: Texas Instruments
Voltage - Supply, Single (V+): 10V ~ 36V
Multiplexer/Demultiplexer Circuit: 4:1
Current - Leakage (IS(off)) (Max): 20pA
Crosstalk: -105dB @ 1MHz
Voltage - Supply, Dual (V±): ±5V ~ 18V
Packaging: Cut Tape (CT)
Channel-to-Channel Matching (ΔRon): 1.5Ohm
Charge Injection: -0.41pC
Supplier Device Package: 14-TSSOP
-3db Bandwidth: 500MHz
Base Part Number: TMUX61
Mounting Type: Surface Mount
Channel Capacitance (CS(off), CD(off)): 1.6pF, 3.8pF
Switch Time (Ton, Toff) (Max): 85ns, 53ns
Operating Temperature: -40°C ~ 125°C
Number of Circuits: 1
Series: -
Package / Case: 14-TSSOP (0.173", 4.40mm Width)
Part Status: Active
detail: 1 Circuit IC Switch 4:1 200Ohm 14-TSSOP
