MSP430FR58,59,68,69xx User Guide دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MSP430FR58,59,68,69xx User Guide	دانلود دیتاشیت

RoHS: true
CPU Core: MSP430
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 12bit
Datasheet: Texas Instruments MSP430FR59471IRHAT
CPU Maximum Speed: 16MHz
GPIO Ports Number: 33
Low-Voltage Detect: Yes
Internal Oscillator: Yes
Direct Memory Access: Yes
Program Storage Size: 32KB
Operating Voltage Range: 1.8V~3.6V
Infrared Data Association: Yes
Operating Temperature Range: -40°C~+85°C
Package: QFN-40-EP(6x6)
Manufacturer: Texas Instruments
Series: MSP430™ FRAM
EEPROM Size: -
Oscillator Type: Internal
Mounting Type: Surface Mount
Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, WDT
Data Converters: A/D 14x12b
Packaging: Cut Tape (CT)
Core Processor: CPUXV2
Number of I/O: 33
Program Memory Size: 32KB (32K x 8)
Core Size: 16-Bit
Connectivity: I²C, IrDA, SCI, SPI, UART/USART
Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
Supplier Device Package: 40-VQFN (6x6)
Base Part Number: 430FR59471
Program Memory Type: FRAM
RAM Size: 1K x 8
Package / Case: 40-VFQFN Exposed Pad
Speed: 16MHz
Part Status: Active
Operating Temperature: -40°C ~ 85°C (TA)
detail: CPUXV2 MSP430™ FRAM Microcontroller IC 16-Bit 16MHz 32KB (32K x 8) FRAM 40-VQFN (6x6)
