TLC5924RHBT 数据手册
其他文档
TLC5924 33 pages
技术规格
- RoHS: true
- Type: Linear
- Category: Nixie Tube Driver/LED Driver/LED Drivers
- Channels: 16
- Topology: Shift Register
- Datasheet: Texas Instruments TLC5924RHBT
- Input Voltage: 3V~5.5V
- Output Current: 80mA
- Output Voltage: 15V
- Switch Frequency: 30MHz
- Operating temperature: -40°C~+85°C
- Package: VQFN-32
- Manufacturer: Texas Instruments
- Current - Output / Channel: 80mA
- Internal Switch(s): Yes
- Supplier Device Package: 32-VQFN (5x5)
- Dimming: -
- Voltage - Supply (Min): 3V
- Applications: Backlight
- Voltage - Supply (Max): 5.5V
- Mounting Type: Surface Mount
- Base Part Number: TLC592
- Packaging: Cut Tape (CT)
- Voltage - Output: 15V
- Series: -
- Package / Case: 32-VFQFN Exposed Pad
- Number of Outputs: 16
- Part Status: Active
- Frequency: 30MHz
- detail: LED Driver IC 16 Output Linear Shift Register Dimming 80mA 32-VQFN (5x5)
