DRV8304SRHAR دیتاشیت

DRV8304SRHAR

مشخصات دیتاشیت

نام دیتاشیت DRV8304SRHAR
حجم فایل 101.144 کیلوبایت
نوع فایل pdf
تعداد صفحات 66

دانلود دیتاشیت DRV8304SRHAR

دانلود دیتاشیت

سایر مستندات

DRV8304 65 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Texas Instruments DRV8304SRHAR
  • Fall Time: 150ns
  • Load Type: MOSFET
  • Rise Time: 300ns
  • Supply Voltage: 6V~38V
  • Number of Drivers: 3
  • Driven Configuration: High Side;Low Side
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Peak Output Current(sink): 300mA
  • Peak Output Current(source): 150mA
  • Package: QFN-40-EP(6x6)
  • Manufacturer: Texas Instruments
  • Channel Type: 3-Phase
  • Gate Type: N-Channel MOSFET
  • Rise / Fall Time (Typ): 300ns, 150ns
  • Supplier Device Package: 40-VQFN (6x6)
  • Mounting Type: Surface Mount
  • Current - Peak Output (Source, Sink): 150mA, 300mA
  • Input Type: Non-Inverting
  • Base Part Number: DRV830
  • Packaging: Cut Tape (CT)
  • Voltage - Supply: 6V ~ 38V
  • Series: -
  • Package / Case: 40-VFQFN Exposed Pad
  • Part Status: Active
  • Logic Voltage - VIL, VIH: 0.8V, 1.5V
  • detail: High-Side or Low-Side Gate Driver IC Non-Inverting 40-VQFN (6x6)
