دیتاشیت STM32G473VCT6
مشخصات دیتاشیت
| نام دیتاشیت | STM32G473xB, STM32G473xC, STM32G473xE Datasheet |
|---|---|
| حجم فایل | 2778.166 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 223 |
دانلود دیتاشیت STM32G473xB, STM32G473xC, STM32G473xE Datasheet |
STM32G473xB, STM32G473xC, STM32G473xE Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- CPU Core: ARM Cortex-M4
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: STMicroelectronics STM32G473VCT6
- CPU Maximum Speed: 170MHz
- GPIO Ports Number: 86
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Direct Memory Access: Yes
- Program Storage Size: 256KB
- Universal Serial Bus: Yes
- Operating Voltage Range: 1.71V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Package: LQFP-100(14x14)
- Manufacturer: STMicroelectronics
- Series: STM32G4
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M4
- Core Size: 32-Bit
- Speed: 170MHz
- Connectivity: CANbus, I²C, IrDA, LINbus, QSPI, SAI, SPI, UART/USART, USB
- Peripherals: Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
- Number of I/O: 86
- Program Memory Size: 256KB (256K x 8)
- Program Memory Type: FLASH
- EEPROM Size: -
- RAM Size: 128K x 8
- Voltage - Supply (Vcc/Vdd): 1.71V ~ 3.6V
- Data Converters: A/D 42x12b; D/A 4x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 100-LQFP
- Supplier Device Package: 100-LQFP (14x14)
- detail: ARM® Cortex®-M4 STM32G4 Microcontroller IC 32-Bit 170MHz 256KB (256K x 8) FLASH 100-LQFP (14x14)
