دیتاشیت TPS7A8300RGRR

مشخصات دیتاشیت

دانلود دیتاشیت TPS7A8300 Datasheet	TPS7A8300 Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TPS7A8300RGRR
Output Type: -
Package: QFN-20-EP(3.5x3.5)
Manufacturer: Texas Instruments
Series: -
Voltage - Output (Max): 5V
Output Configuration: Positive
Voltage Dropout (Max): 0.2V @ 2A
Packaging: Cut Tape (CT)
Voltage - Output (Min/Fixed): 0.8V
Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
PSRR: 40dB (1MHz)
Supplier Device Package: 20-VQFN (3.5x3.5)
Current - Quiescent (Iq): 4mA
Base Part Number: TPS7A8
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 125°C (TJ)
Number of Regulators: 1
Voltage - Input (Max): 6.5V
Current - Output: 2A
Part Status: Active
Current - Supply (Max): 5mA
Control Features: Enable, Power Good, Soft Start
Package / Case: 20-VFQFN Exposed Pad
detail: Linear Voltage Regulator IC 1 Output 2A 20-VQFN (3.5x3.5)
