ADS1120IRVAT دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADS1120IRVAT |
|---|---|
| حجم فایل | 92.51 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 75 |
دانلود دیتاشیت ADS1120IRVAT |
دانلود دیتاشیت |
|---|
سایر مستندات
Connected Sensors Building Automation Systems Guide 13 pages
ADS1120 Datasheet 74 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments ADS1120IRVAT
- Package: QFN-16-EP(3.5x3.5)
- Manufacturer: Texas Instruments
- Architecture: Sigma-Delta
- Sampling Rate (Per Second): 2k
- Series: -
- Voltage - Supply, Analog: 2.3V ~ 5.5V
- Input Type: Differential, Single Ended
- Number of A/D Converters: 1
- Number of Bits: 16
- Voltage - Supply, Digital: 2.3V ~ 5.5V
- Packaging: Cut Tape (CT)
- Reference Type: External, Internal, Supply
- Ratio - S/H:ADC: -
- Configuration: MUX-PGA-ADC
- Supplier Device Package: 16-VQFN (3.5x3.5)
- Data Interface: SPI
- Base Part Number: ADS1120
- Features: PGA, Temperature Sensor
- Number of Inputs: 2, 4
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Part Status: Active
- Package / Case: 16-VFQFN Exposed Pad
- detail: 16 Bit Analog to Digital Converter 2, 4 Input 1 Sigma-Delta 16-VQFN (3.5x3.5)
