TPS73HD325PWPR دیتاشیت

TPS73HD325PWPR

مشخصات دیتاشیت

نام دیتاشیت TPS73HD325PWPR
حجم فایل 91.524 کیلوبایت
نوع فایل pdf
تعداد صفحات 39

مشاهده دیتاشیت TPS73HD325PWPR

دانلود دیتاشیت

سایر مستندات

TPS73HD301, 318, 328 Datasheet 38 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments TPS73HD325PWPR
  • Output Current: 750mA
  • Output Voltage: 2.5V;3.3V
  • Dropout Voltage: 0.8V@(750mA)
  • Output Polarity: positive
  • Number of Outputs: 2
  • Maximum Input Voltage: 10V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 415uA
  • Package: HTSSOP-28
  • Manufacturer: Texas Instruments
  • Series: -
  • Voltage - Output (Max): -
  • Output Configuration: Positive
  • Output Type: Fixed
  • Voltage Dropout (Max): -, 0.8V @ 750mA
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Min/Fixed): 2.5V, 3.3V
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • PSRR: 51dB ~ 49dB (120Hz)
  • Supplier Device Package: 28-HTSSOP
  • Current - Quiescent (Iq): 415µA
  • Base Part Number: TPS73
  • Mounting Type: Surface Mount
  • Number of Regulators: 2
  • Voltage - Input (Max): 10V
  • Current - Output: 750mA
  • Part Status: Active
  • Current - Supply (Max): 550µA
  • Control Features: Enable, Reset
  • Package / Case: 28-PowerTSSOP (0.173", 4.40mm Width)
  • detail: Linear Voltage Regulator IC 2 Output 750mA 28-HTSSOP
