ADS131M04IPWT دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADS131M04IPWT |
|---|---|
| حجم فایل | 118.888 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 105 |
دانلود دیتاشیت ADS131M04IPWT |
دانلود دیتاشیت |
|---|
سایر مستندات
ADS131M04 Datasheet 98 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments ADS131M04IPWT
- Interface: serial;SPI
- resolution: 24Bit
- Supply Voltage: 2.7V~3.6V
- differential input: Yes
- number of channels: 4
- sampling frequency: 32kHz
- Operating Temperature: -40°C~+125°C
- Package: TSSOP-20
- Manufacturer: Texas Instruments
- Architecture: Sigma-Delta
- Sampling Rate (Per Second): 32k
- Series: -
- Voltage - Supply, Analog: 2.7V ~ 3.6V
- Input Type: Differential
- Number of A/D Converters: 4
- Number of Bits: 24
- Voltage - Supply, Digital: 1.65V ~ 2V
- Packaging: Cut Tape (CT)
- Reference Type: Internal
- Ratio - S/H:ADC: 0:1
- Configuration: ADC
- Supplier Device Package: 20-TSSOP
- Data Interface: Serial, SPI
- Base Part Number: ADS131
- Features: PGA
- Number of Inputs: 4
- Mounting Type: Surface Mount
- Part Status: Active
- Package / Case: 20-TSSOP (0.173", 4.40mm Width)
- detail: 24 Bit Analog to Digital Converter 4 Input 4 Sigma-Delta 20-TSSOP
