دیتاشیت STM32H745BIT6

STM32H745x(I, G) Datasheet

مشخصات دیتاشیت

نام دیتاشیت STM32H745x(I, G) Datasheet
حجم فایل 3506.52 کیلوبایت
نوع فایل pdf
تعداد صفحات 252

دانلود دیتاشیت STM32H745x(I, G) Datasheet

STM32H745x(I, G) Datasheet Datasheet

مشخصات

  • RoHS: true
  • CPU Core: ARMOther series
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • Watchdog: Yes
  • ADC (Bit): 16bit
  • DAC (Bit): 12bit
  • Datasheet: STMicroelectronics STM32H745BIT6
  • LCD Module: Yes
  • CPU Maximum Speed: 240MHz;480MHz
  • GPIO Ports Number: 148
  • Low-Voltage Detect: Yes
  • Internal Oscillator: Yes
  • Direct Memory Access: Yes
  • Program Storage Size: 2MB
  • Universal Serial Bus: Yes
  • Operating Voltage Range: 1.62V~3.6V
  • Infrared Data Association: Yes
  • Operating Temperature Range: -40°C~+85°C
  • Secure Digital Input and Output: Yes
  • Package: LQFP-208(28x28)
  • Manufacturer: STMicroelectronics
  • Series: STM32H7
  • Packaging: Tray
  • Part Status: Active
  • Core Processor: ARM® Cortex®-M4, Cortex®-M7
  • Core Size: 32-Bit Dual-Core
  • Speed: 240MHz, 480MHz
  • Connectivity: CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG
  • Peripherals: Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
  • Number of I/O: 148
  • Program Memory Size: 2MB (2M x 8)
  • Program Memory Type: FLASH
  • EEPROM Size: -
  • RAM Size: 1M x 8
  • Voltage - Supply (Vcc/Vdd): 1.62V ~ 3.6V
  • Data Converters: A/D 32x16b; D/A 2x12b
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 208-LQFP
  • Supplier Device Package: 208-LQFP (28x28)
  • detail: ARM® Cortex®-M4, Cortex®-M7 STM32H7 Microcontroller IC 32-Bit Dual-Core 240MHz, 480MHz 2MB (2M x 8) FLASH 208-LQFP (28x28)
