TLC1543IDWR دیتاشیت

TLC1543IDWR

مشخصات دیتاشیت

نام دیتاشیت TLC1543IDWR
حجم فایل 87.685 کیلوبایت
نوع فایل pdf
تعداد صفحات 37

دانلود دیتاشیت TLC1543IDWR

دانلود دیتاشیت

سایر مستندات

TLC1542I/M/Q/C, TLC1543C/I/Q 37 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Texas Instruments TLC1543IDWR
  • Package: SOP-20-300mil
  • Manufacturer: Texas Instruments
  • Architecture: SAR
  • Sampling Rate (Per Second): 38k
  • Series: -
  • Voltage - Supply, Analog: 5V
  • Input Type: Single Ended
  • Number of A/D Converters: 1
  • Number of Bits: 10
  • Voltage - Supply, Digital: 5V
  • Packaging: Cut Tape (CT)
  • Reference Type: External
  • Ratio - S/H:ADC: 1:1
  • Configuration: MUX-S/H-ADC
  • Supplier Device Package: 20-SOIC
  • Data Interface: SPI
  • Base Part Number: TLC154
  • Features: Selectable Address
  • Number of Inputs: 11
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Package / Case: 20-SOIC (0.295", 7.50mm Width)
  • detail: 10 Bit Analog to Digital Converter 11 Input 1 SAR 20-SOIC
