دیتاشیت LM2677SD-5.0/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM2677 |
|---|---|
| حجم فایل | 1546.5 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 34 |
دانلود دیتاشیت LM2677 |
LM2677 Datasheet |
|---|
مشخصات
- Package / Case: 14-VDFN Exposed Pad
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Base Part Number: LM2677
- Packaging: Cut Tape (CT)
- Operating Temperature: -40°C ~ 125°C (TJ)
- Frequency - Switching: 260kHz
- Supplier Device Package: 14-VSON (5x6)
- Part Status: Obsolete
- Current - Output: 5A
- Number of Outputs: 1
- Series: SIMPLE SWITCHER®
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 40V
- Synchronous Rectifier: No
- Voltage - Output (Min/Fixed): 5V
- Voltage - Input (Min): 8V
- Mounting Type: Surface Mount
- Voltage - Output (Max): -
- Output Type: Fixed
- detail: Buck Switching Regulator IC Positive Fixed 5V 1 Output 5A 14-VDFN Exposed Pad
