TPS767D301PWPR 数据手册
其他文档
TPS767D3xx 23 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TPS767D301PWPR
- Output Type: -
- Package: TSSOP-28-EP
- Manufacturer: Texas Instruments
- Operating Temperature: -40°C ~ 125°C
- Base Part Number: TPS767
- Supplier Device Package: 28-HTSSOP
- Voltage - Output (Max): -
- Output Configuration: Positive
- Current - Quiescent (Iq): 125µA
- PSRR: 60dB (1kHz)
- Voltage Dropout (Max): 0.58V @ 1A
- Number of Regulators: 2
- Mounting Type: Surface Mount
- Packaging: Cut Tape (CT)
- Voltage - Output (Min/Fixed): 3.3V, 1.5 V ~ 5.5 V
- Protection Features: Over Current, Over Temperature, Reverse Polarity
- Series: -
- Voltage - Input (Max): 10V
- Current - Output: 1A
- Part Status: Active
- Package / Case: 28-PowerTSSOP (0.173", 4.40mm Width)
- Control Features: Enable, Reset
- detail: Linear Voltage Regulator IC 2 Output 1A 28-HTSSOP
