دیتاشیت TPS767D318PWPR
مشخصات دیتاشیت
| نام دیتاشیت |
TPS767D3xx
|
| حجم فایل |
1663.207
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
23
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS767D318PWPR
-
Output Type:
Fixed
-
Output Current:
1A
-
Output Voltage:
1.8V;3.3V
-
Dropout Voltage:
575mV@(1A)
-
Output Polarity:
Positive
-
Number of Outputs:
2
-
Maximum Input Voltage:
10V
-
Power Supply Rejection Ratio (PSRR):
60dB@(1kHz)
-
Package:
TSSOP-28-EP
-
Manufacturer:
Texas Instruments
-
Operating Temperature:
-40°C ~ 125°C
-
Base Part Number:
TPS767
-
Supplier Device Package:
28-HTSSOP
-
Voltage - Output (Max):
-
-
Output Configuration:
Positive
-
Current - Quiescent (Iq):
125µA
-
PSRR:
60dB (1kHz)
-
Voltage Dropout (Max):
0.58V @ 1A
-
Number of Regulators:
2
-
Mounting Type:
Surface Mount
-
Packaging:
Cut Tape (CT)
-
Voltage - Output (Min/Fixed):
1.8V, 3.3V
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity
-
Series:
-
-
Voltage - Input (Max):
10V
-
Current - Output:
1A
-
Part Status:
Active
-
Package / Case:
28-PowerTSSOP (0.173", 4.40mm Width)
-
Control Features:
Enable, Reset
-
detail:
Linear Voltage Regulator IC 2 Output 1A 28-HTSSOP
