TLC5620CDR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TLC5620CDR |
|---|---|
| حجم فایل | 99.235 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 17 |
دانلود دیتاشیت TLC5620CDR |
دانلود دیتاشیت |
|---|
سایر مستندات
TLC5620C, TLC5620I Datasheet 17 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
- Datasheet: Texas Instruments TLC5620CDR
- Interface: SPI
- Resolution: 8Bit
- Output Type: Voltage-缓冲
- Settling Time: 10us
- Supply Voltage: 5V
- Integral nonlinearity: ±1LSB;±0.9LSB
- Operating Temperature: 0°C~+70°C
- Package: SOP-14
- Manufacturer: Texas Instruments
- Voltage - Supply, Analog: 5V
- Supplier Device Package: 14-SOIC
- Data Interface: SPI
- Number of D/A Converters: 4
- Mounting Type: Surface Mount
- Number of Bits: 8
- Architecture: String DAC
- Voltage - Supply, Digital: 5V
- Packaging: Cut Tape (CT)
- Differential Output: No
- Reference Type: External
- Series: -
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- INL/DNL (LSB): ±1 (Max), ±0.9 (Max)
- Base Part Number: TLC562
- Part Status: Active
- detail: 8 Bit Digital to Analog Converter 4 14-SOIC
